6 – Modules
When Analog Reference Level is +4 dBu and Digital
Reference Level is -18 dBFS
Status before switching pad
setting
Analog GAIN after
switching pad setting
Analog GAIN: +10 – +44 Same value
PAD ON/Analog GAIN: -10 – +9 +10
PAD OFF/Analog GAIN: +45 – +64 +44
When Analog Reference Level is +4 dBu and Digital
Reference Level is -16 dBFS
Status before switching pad
setting
Analog GAIN after
switching pad setting
Analog GAIN: +8 – +42 Same value
PAD ON/Analog GAIN: -12 – +7 +8
PAD OFF/Analog GAIN: +43 – +62 +42
When Analog Reference Level is +4 dBu and Digital
Reference Level is -14 dBFS
Status before switching pad
setting
Analog GAIN after
switching pad setting
Analog GAIN: +6 – +40 Same value
PAD ON/Analog GAIN: -14 – +5 +6
PAD OFF/Analog GAIN: +41 – +60 +40
When Analog Reference Level is 0 dBu and Digital
Reference Level is -20 dBFS
Status before switching pad
setting
Analog GAIN after
switching pad setting
Analog GAIN: +8 – +42 Same value
PAD ON/Analog GAIN: -12 – +7 +8
PAD OFF/Analog GAIN: +43 – +62 +42
When Analog Reference Level is 0 dBu and Digital
Reference Level is -18 dBFS
Status before switching pad
setting
Analog GAIN after
switching pad setting
Analog GAIN: +6 – +40 Same value
PAD ON/Analog GAIN: -14 – +5 +6
PAD OFF/Analog GAIN: +41 – +60 +40
e Analog GAIN knob
o When the input source of the selected module is
“ANALOG” or “SB-16D connected by built-in Dante”, an
analog gain knob will be shown for this unit or the SB-16D
that can be used to adjust the input level of the MIC/LINE
input jack.
Turn LCD knob 1 (lit red) to adjust it.
When Analog Reference Level is +6 dBu and Digital
Reference Level is -9 dBFS
PAD button setting Range
OFF +3 (default) – +57
ON -17 – +37
When Analog Reference Level is +4 dBu and Digital
Reference Level is -20 dBFS
PAD button setting Range
OFF +12 (default) – +66
ON -8 – +46
When Analog Reference Level is +4 dBu and Digital
Reference Level is -18 dBFS
PAD button setting Range
OFF +10 (default) – +64
ON -10 – +44
When Analog Reference Level is +4 dBu and Digital
Reference Level is -16 dBFS
PAD button setting Range
OFF +8 (default) – +62
ON -12 – +42
When Analog Reference Level is +4 dBu and Digital
Reference Level is -14 dBFS
PAD button setting Range
OFF +6 (default) – +60
ON -14 – +40
When Analog Reference Level is 0 dBu and Digital
Reference Level is -20 dBFS
PAD button setting Range
OFF +8 (default) – +62
ON -12 – +42
When Analog Reference Level is 0 dBu and Digital
Reference Level is -18 dBFS
PAD button setting Range
OFF +6 (default) – +60
ON -14 – +40
o The indicators to the left of the Analog GAIN knobs appear
to light as shown below depending on the input level.
Red: -3 dBFS, Green: -40 dBFS
o When the input source of the selected module is
“ANALOG” or “SB-16D connected by built-in Dante” and
the Stereo Link setting is on, 2 Analog GAIN knobs will be
shown for the linked channels.
Turn LCD knob 1 (lit red) to adjust both together.
To operate them separately, turn the GANG function OFF
on the MODULE (INPUT) screen.
o A black knob that cannot be operated will be shown if the
input source is an SB-16D for which control privileges are
not held.
NOTE
Explanation of Analog GAIN values
When signals at the Analog Reference Level (+6 dBu, +4 dBu,
0 dBu) are input, the Analog GAIN value that becomes the
Digital Reference Level (-9 dBFS, -14 dBFS, -16 dBFS, -18 dBFS,
-20 dBFS) at the digital stage is shown as “0”.
114 TASCAM Sonicview 16/Sonicview 24 V1.1.0
