9 – Various information displays
Version Information Screen
On this screen, information is shown about the system firmware
versions and build numbers, as well as cards installed in SLOT 1
and SLOT 2.
Tap Menu Screen > System Setup > Version Information to open
the Version Information Screen.
Firmware update procedures
ATTENTION
If a snapshot created on a unit with firmware version 1.1.0 or
later is recalled by a unit with firmware version 1.0.x, proper
operation will not be possible, so the following restriction
applies.
i Downgrading to version 1.0.x is not possible.
i Snapshot/All System Data created on units with firmware
version 1.1.0 or later cannot be imported/restored on
units with firmware version 1.0.x. (Snapshot/All System
Data created by units with firmware version 1.0.x can be
imported/restored on units with firmware version 1.1.0 or
later.)
1. Download the latest firmware from the TEAC Global Site
(https://teac-global.com/).
Decompress the downloaded file if it is in ZIP format or
another compressed file type.
2. Copy the downloaded firmware to the root directory (top
level) of a USB flash drive.
3. Insert the USB flash drive prepared in step 2 into the USB
port on the top panel.
4. Tap Menu Screen > System Setup > Firmware Update to
open the Firmware Update Screen.
5. When the USB flash drive and firmware update file have
been verified, the following screen will appear.
NOTE
i The screen above shows a list of firmware update files in the
root folder of the USB flash drive connected to the USB2.0
port on the front of the unit. The firmware copied in step 2
above should also be shown.
i A maximum of five lines of firmware can be shown at the
same time. If there are more files than can be shown on the
display at once, swipe the list up or down to scroll it.
i The screen shown above is an example. The actual
appearance will differ.
192 TASCAM Sonicview 16/Sonicview 24 V1.1.0
