5 – Routing
Output routing
Use the following screens for output routing.
MIX 1–22 and MAIN L/R Master MODULE
(OVERVIEW) Screens
Tap the MODULE NAME area on the Home Screen to open this
screen.
MIX 1–22 modules
MAIN L/R Master module
1 OUTPUT button
o This shows the name of the output port that the output
signal of the selected module is assigned to. If it has been
assigned to multiple output ports, “…” will appear to the
bottom right of the button.
o If the module is stereo, output port names will appear
split left and right and abbreviated as follows.
Module name
shown
Stereo module name
shown
ANALOG AN
Dante DA
SLOT 1 S1
SLOT 2 S2
USB OUT USB
o If a Dante port that has a mounted SB-16D assigned is
selected, “SB #[ID] [port number]” will be shown.
If it is a virtually-mounted SB-16D, will appear.
o Tap this button to open the OUTPUT PORT SELECT Screen
where output ports can be selected. (See “OUTPUT PORT
SELECT screen” on page 108.)
TASCAM Sonicview 16/Sonicview 24 V1.1.0 99
