RUN EXCITE: Service & Maintenance Manual - rev. 1.5
Page 7.8
7.3. DISASSEMBLING THE HAND SENSOR BOARD AND THE
CSAFE BOARD
Figure 7.3-1
Carry out the procedure described in paragraph
7.1. “Disassembling the display”.
r board a (not
on the 500 model) and the CSafe board b, on
1. This exposes the Hand Senso
the inner side of the rear display support.
Figure 7.3-2
an a (only on the 700 / 700E
c.
To disassemble the boards:
d Sensor board H
and 900 / 900E models):
. Unplug the connectors 1
2. Back off the 3 screws d using a medium
Phillips screwdriver.
3. Remove the hand sensor board.
Figure 7.3-3
Safe board b:
1.
2. B
Ph
. Back off the 2 screws g using a 5-mm Allen
w
C
Disconnect the serial cable e.
ack off the 4 screws f using a medium
illips screwdriver.
3
rench.
Continued on following page →
