Technogym Run Excite 700 - Wiring

RUN EXCITE: Service & Maintenance Manual - rev. 1.5
Page 2.16
2.8. WIRING
TRM-02: High voltage cable
Power entry socket – Circuit breaker
Power entry
socket
Signal Color Circuit breaker
terminal
Faston Neutral Blue 2
Faston Line Brown 4
TRM-03: High voltage cable
Circuit breaker - Filter
Circuit breaker
terminal
Signal Color Filter
terminal
1 Neutral Blue N
3 Line Brown P
TRM-03A: High voltage cable (UL)
Circuit breaker - Filter
Circuit breaker
terminal
Signal Color Filter
terminal
1 Neutral Blue N
3 Line Brown P
TRM-04: High voltage cable
Filter – Relay – Power supply board
Filter
terminal
Signal Color Relay Power supply
board
XA
Blue 4 -
N’ Neutral
Blue - 4
Brown 8 -
P’ Line
Brown - 2
TRM-05: Motor compartment fan cable
Patch connector - Fan
Patch
L
Signal Color Fan
1 24 Vdc power supply Red
2 Gnd Black
internally
connected cable
