7.17. DISASSEMBLING THE TREAD BELT GROUP
With these operations it is possible to disassemble:
• footrest;
• driving roller;
• tread belt motor drive-belt;
• running deck;
• driven roller;
• tread belt;
• shock absorbers.
In order to carry out these operations, it is nece
the belt is to be used again, follow the instructions given in paragraph 8.2. “Tensioning a
used tread belt” to correctly re-tension the belt.
ssary to slacken the tread-belt tension. If
Figure 7.17-1
Carry out the procedure described in paragraph
7.9. “Disassembling the motor guard”, only as
far as removing the upper guard.
the
two hooks a.
1. Remove the dust guard by pressing on
Figure 7.17-2
2. Back off the
using a 4-mm Allen wrench.
3. Back off the two screws c (one on each side)
using a 4-mm Allen wrench.
4. Remove the rear cover as indicated by the
arrows.
5. Then remove both footrests by pulling them
toward the back.
two screws b (one on each side)
Continued on following page →
Page 7.31
