RUN EXCITE: Service & Maintenance Manual - rev. 1.5
Page 7.32
6 R
7. Sl
tw
roller, using an 8-m
. emove component d.
acken the belt tension by backing off the
o screws e which act on the rear machine
m Allen wrench.
Figure 7.17-3
Figure 7.17-4
8. Release the spring f of the tensioning
mechanism between the drive-belt and the
front roller of the tread belt.
Figure 7.17-5
er.
ler, extracting it from
the top on the right side and pulling it out
axially from the left.
9. Disengage the motor drive belt from the
pulley g on the front roll
10. Remove the driving rol
Continued on following page →
