RUN EXCITE: Service & Maintenance Manual - rev. 1.5
Page 7.22
7.12. DISASSEMBLING THE ELECTRONICS BOARDS
Figure 7.12-1
Carry out the procedure described in paragraph
7.9. “Disassembling the motor guard”, only as
far as removing the upper guard.
1. Back off the 4 screws a using a medium
Phillips screwdriver.
2. Lift up the cover.
Figure 7.12-2
1.
s
board.
To reassemble the electronics boards:
Power supply board:
Unplug all the connectors.
2. Back off the screw b using a small Phillip
screwdriver.
3. Open the 3 remaining clips c (2 are obscured
in the photo).
. Remove the circuit 4
Figure 7.12-3
Elevation + Cutout Board:
1. U
. Open the clip fasteners d (2 are obscured in
the photo).
3. Remove the circuit board.
nplug all the connectors.
2
Continued on following page →
