RUN EXCITE: Service & Maintenance Manual - rev. 1.5
7.4.2. 700E / 900E WELLNESS TV VERSIONS
Figure 7.4-3
Carry out the procedure described in paragraph
7.1. “Disassembling the display”.
rs a, of the
keyboard and of the headphone jack.
in the
figure, that are fixing the plate with the
circuit boards to the front display covering.
1. Disconnect the 2 connecto
2. Back off the 11 screws indicated
Figure 7.4-4
3. Back off the 2 screws b that are fixing the
headphone jack, using a small Philips
screwdriver.
Figure 7.4-5
4.
th
5. L which all the circuit
boards and LCD are fixed.
Pull the connector out of its seat and unplug
e connector indicated in the figure.
ift up the plate to
Continued on following page →
Page 7.11
