Technogym Run Excite 700 - Disassembling the Motor Compartment Fan and the Limit Switch

RUN EXCITE: Service & Maintenance Manual - rev. 1.5
Page 7.20
7.10. DISASSEMBLING THE MOTOR COMPARTMENT FAN
AND THE LIMIT SWITCH
Figure 7.10-1
Carry out the procedure described in paragraph
ws a using a medium
r.
3. Remove the fan.
Disassembling the limit switch:
mit switch
to the electrical box.
crews b using an 8-mm
wrench and remove the limit switch from the
To e fan and the limit switch, carry
7.9. “Disassembling the motor guard”.
Disassembling the fan:
1. Unplug the electrical cable connecting the
fan to the electrical box.
Back off the 3 scre2.
Phillips screwdrive
4. Unplug the cable connecting the li
5. Back off the two s
guard.
reassemble th
out the above steps in reverse order.
After reassembling the microswitch,
check its alignment.
