RUN EXCITE: Service & Maintenance Manual - rev. 1.5
7.6. DISASSEMBLING THE EMERGENCY BUTTON
Figure 7.6-1
1.
2. s a using a small Philips
screwdriver.
Turn off the machine and unplug the mains
lead from the wall outlet.
Back off the 4 screw
Figure 7.6-2
3. Disconnect the two Faston connectors
4. cy button.
T e
the ab
indicated in the figure from the emergency
button.
Remove the emergen
o r assemble the emergency button, carry out
ove steps in reverse order.
Page 7.15
