RUN EXCITE: Service & Maintenance Manual - rev. 1.5
Page 7.24
7.13. DISASSEMBLING THE INVERTER
Figure 7.13-1
ed in paragraph
7.9. “Disassembling the motor guard”, only as
far as removing the upper guard.
1. Back off the 4 screws a using a medium
Phillips screwdriver.
Carry out the procedure describ
2. Lift up the cover.
Figure 7.13-2
3. Disconnect all the cables entering the
inverter indicated in the figure.
4. On the opposite side, unplug the serial
communication cable connected to the
5.
nother two are on the
opposite side).
6. Lift up the inverter from
To re
steps
download board.
Back off the screws b using a medium
Phillips screwdriver (a
the electrical box.
assemble the inverter, carry out the above
in reverse order.
ELTRA encoder Æ P60=360
If the inverter is replaced, after
completing the procedure check that
parameter P60 is correctly configured as
a function of the type of encoder
installed on the machine:
HEDR encoder Æ P60=100
