RUN EXCITE: Service & Maintenance Manual - rev. 1.5
Figure 7.12-4
1. Unplug all the connectors.
2. Back off the 4 screws e (in the photo 2 are
obscured), using a small hex screwdriver.
3. Remove the circuit board.
rry out
e above steps in reverse order.
Download Board:
To reassemble the electronics boards, ca
th
Page 7.23
