RUN EXCITE: Service & Maintenance Manual - rev. 1.5
7.11. DISASSEMBLING THE ELECTRICAL BOX
Figure 7.11-1
as
a
m Allen
wrench.
2. Remove the entire box from its compartment
in the machine.
3. Disconnect the cables entering the electrical
box at the front and on the side of the motor:
• Power supply cable;
• Cable connecting upper and lower
assemblies (TRM-19);
• Limit switch cable (TRM-10);
• Ground connection cable;
• Fan cable (TRM-05);
• Tread belt motor cable (TRM-06);
• Tread belt motor encoder cable (TRM-
07);
• Elevation motor cable (TRM-08).
To reassemble the electrical box, carry out the
above steps in reverse order.
Carry out the procedure described in paragraph
r guard”, only7.9. “Disassembling the moto
r s removing the upper guard. fa
1. Back off the screws a (there are another two
on the opposite side) using a 4-m
Page 7.21
