RUN EXCITE: Service & Maintenance Manual - rev. 1.5
TRM-06: Belt motor cable
Patch connector - Motor
Patch
I
Signal Color Motor
1 U Black 1
2 V Black 2
3 W Black 3
4 thermal cutout + Black 4
5 thermal cutout - Black 5
6 GND Black 6
internally
connected cable
TRM-07: Encoder cable
Patch connector - Encoder
Patch
H
Signal Color Encoder
1 Gnd Red 1
2 Out 1 Red 3
3 +5 Vdc power supply for encoder Red 4
4 Out 2 Red 5
TRM-08: Elevation motor cable
Patch connector – Elevation motor
Patch
G
Signal Color Elevation motor
1 Motor - Black
2 Motor + Black
4 Gnd Black
5 +5 Vdc power supply for encoder Red
6 Pulses White
internally
connected cable
TRM-10: Limit switch cable
Patch connector – Limit switch
Patch
M
Signal Color Limit switch
1 Reference Brown COM 1
2 Contact White NC 2
Page 2.17
