RUN EXCITE: Service & Maintenance Manual - rev. 1.5
Page 2.18
TRM-14: Inverter power supply cable
Relay - Inverter
Relay Signal Color Inverter
2 Line Blue L1
6 Neutral Brown L2
TRM-15: Emergency button cable
Patch connector - Microswitch
Patch
B
Signal Color Micro 1 Micro 2
1 Emergency Brown C -
2 Reference White - C
- Bridge Black NC NC
TRM-18: Electrical box power supply cable
Download board – Elevation board – Power supply board
Elevation board
Download
board
X2
Signal Color
X1 X4
Power supply
board
XU
Gray 4 - -
2 Gnd +12 Vdc
Gray - - 7
3 Gnd +5 Vdc Black - - 9
4 -sensing +5 Vdc White - - 8
Orange 3 - -
6 +12 Vdc
Orange - - 2
7 + 5 Vdc Red - - 4
8 +sensing +5 Vdc Yellow - - 3
9 Emergency Purple - 2 -
10 Reset Blue - 4 -
11 +12 Vdc isolated Red - 1 -
12
Gnd +12 Vdc
isolated
Black - 3 -
- Gnd +24 Vdc Brown 2 - 10
- +24 Vdc Pink 1 - 5
To Next Page
