Figure 7.7-4
3. cardio receiver as
shown in the picture.
n.
Fold the sponge on the
4. Secure the sponges on the receiver with some
tape or with a cable tie. Make sure they are
secured but not too faste
5. Mark the sponge in order to remember the
position of the coil.
Figure 7.7-5
6. e cardio receiver in a plastic bag.
e as possible to the
Encase th
7. Close and secure the plastic bag with some
tape on the cable as clos
cardio receiver, as indicated in the figure.
Figure 7.7-6
8. Let out from the handlebar hole just the
required cable to position the receiver into
the plastic housing.
the receiving coil must be oriented
upwards and toward the user (as shown
in the figure to side).
Page 7.17
