RUN EXCITE: Service & Maintenance Manual - rev. 1.5
Page 8.4
Figure 8.3-3
ollows:
•
If the tread belt drags to the right, position
the table as f
Leave a few millimeters of space free
between the corner of the table and the
frame.
Figure 8.3-4
• If the tread belt drags to the left, position
the table as follows:
Leave a few millimeters of space free
between the corner of the table and the
frame.
Figure 8.3-5
4. Tighten the 2 screws b using a torque wrench
adjusted to 20 Nm.
5. Start the tread belt at 5 Km/h and, while
walking on it, make sure that the belt remains
centered.
6. Tighten the 4 screws e (two for each
bushing) fastening the 2 eccentric bushings
to the table.
