Placing the machine into operation
7�3 Adjustment of limit switches
The limit switches are for determining the position of the discharge slide.
1
1
Fig. 35: Adjustment of the limit switches (depicted without a discharge protector)
1 Limit switches
Set the motion restriction for the slide by the various limit switches (1) with screws so that the
slide does not hit the mechanical limit stop.
7�4 Lubrication
The lubrication of the machine and its components must take place promptly and regularly in
accordance with the inspection and maintenance schedule (see 10.3 "Lubrication plan" and
Maintenance schedule").
