Options
13 Options
13�1 Water distribution
13�1�1 Ring line with nozzles
1
3
2
Fig. 61: Ring line
1 Ring line
2 Nozzle
3 Water connection
NOTE
► The connection of the water line at the customer's site must
takeplaceusingaexiblesection!
► Only use with fresh water�
