Page 75 of 957.10-00110b_en
Maintenance
10�2 Check hydraulic system
10�2�1 Checking the transmission oil level
1. Check the oil level using the oil dipstick (1).
Max. oil level: Top marking ("max") on the oil dipstick.
2. If necessary, add oil through the oil nozzle (2); for the oil quality, see "Lubricant
recommendation".
1
2
Fig. 56: Checking the oil level
1 Oil dipstick
2 Oil nozzle
