Options
13�4 Central lubrication system of mixing arm bearings
1. Remove the cover cap (3) on the lubrication connector (2).
2. Place the lubricating grease pump onto the lubrication connector (2).
3. Fill the central lubrication system (1) with grease.
4. Remove the lubricating grease pump.
5. Place the cover cap (3) back onto the lubrication connector (2).
1
3
2
Fig. 66: Central lubrication
1 Central lubrication unit
2 Lubrication connector
3 Cover cap
