Page 79 of 957.10-00110b_en
Maintenance
10�2�5 Venting of the swivel drive of the discharge slide
After each oil change or in the case of any slackness of the discharge slide, the hydraulics of
the swivel drive must be vented.
For this purpose, open the vent screws (1) and open and close the discharge slide, until oil
comes out.
Close the vent screws again.
The vent screws (1) are located on the top part of the drive.
1
3
2
1
Fig. 60: Venting the discharge slide
1 Vent screws
2 Discharge slide drive
3 Lubrication line
