Maintenance
Scraper (standard)
1
2
3
4
5
6
Fig. 54: Scraper (standard)
1 Outer wall wear plate
2 Mixing trough
3 Screw connection (mounting)
4 Clamp
5 Scraper
6 Discharge slide wear liner
Plastic scraper (optional)
1
2
3
4
5
6
Fig. 55: Plastic scraper (optional)
1 Outer wall wear plate
2 Mixing trough
3 Screw connection (mounting)
4 Clamp
5 Scraper
6 Discharge slide wear liner
