Tektronix DPO70000C/DX Series User Manual

Error detector setups Set up the s erial error detector
To use
When you select the Custom_Setup, additional controls are put on the display so you can browse
for a setup file. The usual idea is to start with a setup that is close to what you want, use the UI
to specify the settings you desire, and then save the result. When you enter a new name for the
file in the file
name text control, press Enter to have your editing changes accepted. Then select
the Save button to actually save the setup into the file. To recall a setup file, just browse to the
file you want a nd select Open. The default location for Error Detector setup files in Win7 is
C:\Users\Public\Tektronix\TekScope\ErrorDetector.
From the Source Setup tab, select the Serial Bus, Data Rate and signal Source from the drop-down
lists.
Click the Error Detection option button for the type of error you want to detect.
Press Advanced, to open the Advanced Settings window.
Click Er
ror Detector Data Rates
(see page 201) and Error Det ector Standards and Buses (see page 201) to
display the data rates, standards and buses supported by the Serial Error Detector.
What do
you want to do next?
Use the Error Detector. (see page 199)
Set e rror detector advanced settings. (see page 203)
Specify the error detector test pattern. (see page 204)
Set the error detector stop condition. (see page 205)
Data Rates Supported by the Error Detector
The range of data rates supported by the serial error detector matches the 8b/10b serial pattern trigger
range. The serial error detector will test 8b/10b-encoded data with following range of data rates: 1.25 to
1.65, 2.0 to 3.25, 3 .5 to 5.2, and 5.3 to 6.25 GBaud.
Standards and Buses Supported by the Error Detector
T
he serial error detector has several presets for industry standards. In addition, there is a generic 8b/10b
preset. Each of these presets configure the error detector for the test types specified by the industry
standard or for the test type that makes sense for the current setup.
The test type s (bit, frame, symbol, or character error) supported for each industry standard and for the
generic 8b/10b bus are listed in the following table.
Table 1: (Category) specifications
Test type
Standard
Bit Frame
Symbol Character
SATA
Yes Yes No Yes
USB
Yes No Yes Yes
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 201
