Tektronix DPO70000C/DX Series User Manual

Trigger setups Edit the visual trigger expression
Edit the visual trigger expression
From the Visual Trigger menu, double click the Visual Trigger expression.
To use
Click in the readout field to enter the visual trigger expression.
Click a button to enter its character or operator into the expression.
Use the Text Edit Controls (see page 259) to move the insertion point (cursor) within the expression.
Behavior
The characters are entered into the expression one at a time.
What do you want to do next?
Learn about visual trigger setup (see page 459)
Learn about creating a visual trigger area. (see page 461)
Learn a
bout controlling visual triggering.
(see page 462)
Learn about saving a visual trigger setup. (see page 472)
Learn about recalling a visual trigger setup. (see page 473)
Learn about visual trigger qualification. (see page 467)
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 469
