How to ? Editing MyScope control windows
1. From the MyScope menu, select Edit Control Window.
2. Select the MyScope control window that you want to edit from the Edit MyScope Control Window
dialog box. The c ontrol window you selected opens in the MyScope Setup control window.
3. Edit the control window using the same procedures as you did to create the control window.
(see
page 599)
4. Click Save to save your changes to this control window.
5. Click Save As to save your changes as a different control window. Enter a unique name for
your MyScope control window, and click Save. The default location to save MyScope files is
C:\Users\[Username]\Tektroni x\TekScope\MySco pe.
Creating
MyScope control windows
Use this procedure to create your own control windows:
1. From the MyScope menu, select New Control Window.
2. Clickonthe(+)toexpandacontrolgroupandsee the available controls within that group.
3. Click on a selection to see the control in the preview window.
4. Clear the check boxes for any controls that you do not want to appear. Most controls show
all check boxes selected by default.
5. Drag the customized control to your MyScope control window. You can also move a control after
it has been p laced in the new control window by dragging it.
6. To remove the control from the custom control window select it, and then click the Delete button.
7. Cli
ck New Tab to add up to eight tabs.
8. Click the Rename Tab to create a unique name for each tab in your control window.
9. Click the User Pre button, and then select the user preferences you want to apply to this control
window.
10. By default, the preferences are the same as what is currently set on your instrument. The
preferences you set from the MyScope Setup window only apply to your MyScope control
w
indow. The preferences will take effect when the MyScope control window is a ctivated.
11. ClickSaveorSaveAstosaveyourMyScopecontrolwindow.
12. Enter a unique name for your MyScope control window and click Save. (This name will display
in the upper right corner of the control window when you open it.) The default location to save
MyScope files is
C:\Users\[Username]\Tektroni x\TekScope\MySco pe.
13. From the MyScope menu, click Open C ontrol Window….
14. Select the MyScope control window that you want from the Open MyScope Control Window
dialog box, and then click Open.
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 599
