Oscilloscope Reference SPI bus trigger polarity
SPI bus trigger polarity
The SS, MISO, and MOSI Active controls allow you to select when the enable is active.
Select (H) High or (L) Low from the drop-down menu.
The SCLK Active control provides compensation for inverted signals or synchronization on the falling
edge of the clock.
Select Rising or Falling from the drop-down menu.
SPI bus trigger threshold
1. Click in the SS Threshold or SCLK Threshold entry boxes.
2. Use the multipurpose knobs to set the threshold voltage levels for the trigger.
SPI data source
In the drop-down list box, specify the MISO and or MOSI data source.
Supported ADEs
TekVISA supports these Application Development Environments:
Microsoft C/C++
Microsoft Visual Basic
LabVIEW graphics software using the G language
MATLAB analysis software
TekProbe/TekVPI interfaces
These interfaces enable the instrument to sense information about the probe such as the serial number and
other unique identification information. It also allows the instrument to provide power directly to the probe.
With this information, the instrument can automatically set up its requirements to match the characteristics
of the probe, such as termination and attenuation.
922 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
