TESTO Saveris - Page 147

7 Maintaining the product
146 0970 4020 en 01 testo AG
Saveris Pt/PtD radio probe
Radio probe with an external Pt100 probe connection
Characteristic Values
Probe type Pt100
Measuring range -200 to +600 °C
Accuracy
±0.1 °C (0 to +60 °C)
±0.2 °C (-100 to +200 °C)
±0.5 °C (rest of measuring range)
at 25 °C
Resolution 0.01 °C
Connection 1 Pt100 via mini-DIN socket
Protection class
IP68 (with probe inserted or port sealed
with rubber plug)
Operating
temperature
-20 to +50 °C
