HYDRAULICS
8N-82
Figure 8N-1. 69168 (2WD) Hydraulic Schematic
1.01 ci
3625 psi
3625 psi
58 psi
1.35 ci
A
IN
OUT
Case Drain
B
Gear
Pump
10
Micron
Steering
Valve
In
In
AB
Aux Out
PTC
C
G
G
M1 M2
Out
RT LT
6.6 ci
.070
3200 psi
300
psi
1.27 ci
11.9 ci
11.9 ci
11.9 ci
11.9 ci
LF
Wheel
Motor
LF
Wheel
Motor
Flow Divider Valve
RF
Wheel
Motor
RF
Wheel
Motor
2WD Units
2WD Units with optional
Dierential Lock Kit
Deck
Valve
Lift
Valve
Lift
Cylinder
Oil
Filter
Oil
Cooler
Steering
Cylinder
915 psi
.425 ci
69168 (2WD) Hydraulic Schematic
