HYDRAULICS
8M-80
FLOW TEST REPORT 3
Turfcat Hydraulic Pressure and Flow Record
Traction Pump and Wheel Motors
Model:_____________ Serial:____________________ Hours of Use:__________ Date:_______________
Hydraulic oil temperature when test performed _______________
Engine high idle speed _______________
Traction Pump Test
A) Step 9 – Traction pump no load flow (use Hydro Lock Linkage) _______________
B) Step 10 – Traction pump flow @ 2000 psi (138 Bar) _______________
Result 1 – A) minus B) equals traction pump leakage (______________)
C) Step 11 – Forward high pressure relief valve pressure (______________)
Left Front Wheel Motor
D) Step 20 – Left front wheel motor flow @ 2000 psi (138 Bar) _______________
Result 2 – B) minus D) equals left front wheel motor leakage (______________)
Left Rear Wheel Motor (4WD)
E) Step 29 – Left rear wheel motor flow @ 2000 psi (138 Bar) _______________
Result 3 – B) minus E) equals left rear wheel motor leakage (______________)
Right Front Wheel Motor
F) Step 38 – Right front wheel motor flow @ 2000 psi (138 Bar) _______________
Result 4 – B) minus F) equals right front wheel motor leakage (______________)
Right Rear Wheel Motor (4WD)
G) Step 47 – Right rear wheel motor flow @ 2000 psi (138 Bar) _______________
Result 5 – B) minus G) equals right rear wheel motor leakage (______________)
10 gpm
B) From Pump Test ______________
B) From Pump Test ______________
B) From Pump Test ______________
B) From Pump Test ______________
