ENGINE
3A-1
SECTION 3A. SERVICE TOOLS, MATERIALS, AND SPECIFICATIONS
MATERIALS REQUIRED
l
SPECIFICATIONS
Engine
Make/Model..........................D1305-E3B Kubota Diesel
Cylinders..................................................................... 3
Displacement..............................76.95 cu. in. (1261 cc)
Cooling.....Liquid Cooled/w 15 in (381 mm) 8 blade fan
Air filter..............Donaldson dry type w/evacuator valve
Alternator .......................................................... 40 amp
Max rated horsepower ......29.1 (21.7 kW) @ 3000 rpm
Torque......................59.1 ft-lbs (80.1 Nm) @ 2000 rpm
High idle speed .............................................. 3220 rpm
Low idle speed............................................... 1750 rpm
Fuel capacity....................................9 US gal (34 liters)
Engine Lubrication
Engine oil capacity .......................... 6 quarts (5.7 liters)
Engine oil ...................API Classification CF, CD, or CE
Cooling System
Fan belt deflection........... 0.250 to 0.312 in (6 to 8 mm)
Radiator cap............................................. 15 psi (1 bar)
Thermostat start opening temp. ............ 177°F (80.5°C)
Thermostat completely open temp........... 203°F (95°C)
Anti-freeze.................................... Ethylene glycol base
Anti-freeze mixture.............................. 50/50 with water
Fuel System
Supply Pump Fuel Restriction @ high idle.............4 Hg
Supply Pump Pressure @ High Idle ....... 3 psi (0.2 bar)
Supply Pump Volume @ High Idle..............300 cc/min.
Nozzle Opening Pressure....................1992 to 2133 psi
(137-147 Bar)
Injection nozzle no-leak pressure......1849 psi (127Bar)
Service Specs
Valve Clearance - Cold .....006 -.007 (0.145-0.185 mm)
Compression......................541 to 597 psi (37.3 to 41.1
Bar)
Compression allowable.............................327 psi (22.5
Bar)
Oil Pressure - Idle spd............................7.1psi (49 kPa)
Oil Pressure - Rated Spd.......28.5-64psi (196-441 kPa)
Engine Electrical
Glow Plug Resistance......................................0.9 Ohm
Fuel Shut Off Solenoid.................. Pull-In Coil 0.5 Ohm
Fuel Shut Off Solenoid...................Hold Coil 15.5 Ohm
Tools required:
Standard automotive hand tools
Cleaning
materials:
Stoddard solvent or equivalent
Detergent and water
Anti-Seize
Lubricants:
Refer to Section 11
Other service
items:
Compressed air source
Engine hoist
3A
