Turfcat Hydraulic Pressure and Flow Record
Implement Pump, Deck Valve and Motor Circuit
Model:_____________ Serial:____________________ Hours of Use:__________ Date:_______________
Hydraulic oil temperature when test performed _______________
Engine high idle speed _______________
Implement Pump Test
A) Step 6 – Implement pump no load flow _______________
B) Step 7 – Implement pump flow @ 2000 psi (138 Bar) _______________
Result 1 – A) minus B) equals implement pump leakage (______________)
Deck Valve Test
C) Step 14 – Deck valve flow @ 2000 psi (138 Bar) _______________
Result 2 – B) minus C) equals deck valve leakage (______________)
D) Step 15 – Deck relief valve pressure reading (______________)
Deck Motor Test
E) Step 22 – Deck motor flow @ 2000 psi (138 Bar) _______________
Result 3 – C) minus E) equals deck motor leakage (______________)
B) From Pump Test ______________
C) From Deck Valve Test ______________
To Next Page
