28. RECORDING DATA - TOPO MENU -
Distance measurement data can be stored in the current JOB.
PROCEDURE
1. Press [MEAS] in the first page of
OBS mode to perform distance
measurement.
"12.2 Distance and Angle
Measurement"
2. Press [TOPO] in the third page of
OBS mode. <TOPO> is displayed.
Select “Dist data” to display the
measurement results.
3. Set the following items.
(1) Target height
(2) Point name
(3) Code
4. Check the input data, then press
[REC].
28.4 Recording Distance Measurement Data
TOPO JOB1
Occupy
Angle data
Dist data
Coord data
BS data
OFFSET REC
MEAS
AUTO
ZA
HA-R
HR
PT
SD
CD
:
A
H-SET TILTREC
0SET
