33. CHANGING THE SETTINGS
264
Prism constant correction
Reflective prisms each have their prism constant.
Set the prism constant correction value of the reflective prism you are using.
When selecting "N-prism (Reflectorless)" in "Reflector", prism constant
correction value is set to "0" automatically.
It is possible to allocate the softkeys in OBS mode to suit the measurement
conditions. It is possible to operate the ES efficiently because unique softkey
allocations can be preset to suit various applications and the ways that different
operators handle the instrument.
• The current softkey allocations are retained until they are revised again, even
when the power is cut off.
• It is possible to register two sets of key function allocations: user setting 1 and
user setting 2.
• It is possible to recall the softkey arrays registered for User 1 and User 2 as
necessary.
• When softkey allocations are recorded and registered, the previously recorded
key settings are cleared. When a softkey array is recalled, the key array is
changed to the key array that has been recalled, clearing the previous key
array. Be sure to remember this.
The following are the softkey allocations when the ES was shipped.
Page 1 [MEAS] [SHV] [0SET] [COORD]
Page 2 [MENU] [TILT] [H-SET] [EDM]
Page 3 [MLM] [OFFSET] [TOPO] [S-O]
The following functions can be allocated to the softkeys.
[MEAS] : Distance measurement
[SHV] : Switch between angle display and distance display
[0SET] : Set horizontal angle to 0
[COORD] : Coordinates measurement
[REP] : Repetition measurement
[MLM] : Missing line measurement
[S-O] : Setting-out measurement
33.3 Allocating Key Functions
