5. BASIC OPERATION
22
Status screen
OBS mode screen
Measuring screen
Input screen
* 1 Distance
Switching distance display status: "33.1 Configuration -Config Mode-"
SD : Slope distance
HD : Horizontal distance
VD : Height difference
5.2 Display Functions
ES-103
S/N 123456
Ver. XXX-XX-XX
XXX-XX-XX
Job.JOB1
rec 9999
CNFGOBS USB DATA
Application
software
version
Instrument name
JOB
SHVMEAS 0SET COORD
OBS
SD
ZA
HA-R
Distance *1
Vertical angle *2
Horizontal angle *3
Bluetooth communication status *8
Laser-pointer function / Guide light ON *7
Prism constant value
Atmospheric correction factor
Remaining battery power *4
Tilt angle compensation *6
Page number
Target *5
F
i
n
e
Laser is emited *9
A
Previous page
Next page
Input mode *10
OK
CD
