289

35. CHECKS AND ADJUSTMENTS



• Tightening each of the fine adjustment screws moves the laser plummet beam

in the directions shown below.

Right

Left

Down

Tighten "Up" screw

Tighten "Right"

screw

Tighten "Down" screw

Tighten "Left"

screw

Fine adjustment screws

Laser plummet adjustment cap

pointing towards user
