63
12. DISTANCE MEASUREMENT
•Press [HT] to enter an
instrument height (HI) and a
target height (HR).
• When [REC] is pressed, REM
data is saved.
"28. RECORDING DATA -
TOPO MENU -"
•Press [HT/Z] on the second
page of the REM measurement
to display the Z coordinate for
the height from the ground to the
target. Pressing [HT/Z] again
returns to the height display.
7. Press {ESC} to finish
measurement and return to the
OBS mode screen.
• It is also possible to perform REM measurement by pressing [REM] when
allocated to the OBS mode screen.
"33.3 Allocating Key Functions"
• Inputting instrument and target height: Press [HT] to set instrument and target
height. It can be set also in “Occ. Orientation” of coordinate measurement.
"13.1 Entering Instrument Station Data and Azimuth Angle"
