4.1.32 FXQ Command
Set the measurement mode to FIX FREQ mode and inner-filter type, frequency in FIX FREQ
mode.
FXQ_###_# ： The left side of # means frequency [Hz](1.5 -250).
The right side means inner-filter (1-3 or 5)
PC Command communication direction Measuring instrument
”FXQ_ frequency _ Filter type” + (Cr・Lf)
OK+(Cr･Lf)
4.1.33 IMD Command
Sets the data communication methods
IMD_# ： The pound sign (#) is 0 or 1.
0: Normal type
1: CS900 type
PC Command communication direction Measuring instrument
”IMD_data communication methods” + (Cr・Lf)
OK+(Cr･Lf)
4.1.34 IMDR Command
Reads the data communication methods.
PC Command communication direction Measuring instrument
“IMDR”+(Cr･Lf)
“OK+(Cr･Lf)
data communication methods+(Cr･Lf)
“END” + (Cr･Lf)
