- 63 -
3.19 Maintenance Reminder Screen
Set the behavior of the maintenance reminder screen. This screen displays the number of months
elapsed since purchase or the last calibration test.
There are two settings:
ON: Proceed to the next screen after the buzzer sounding in 5 seconds.
OFF: The screen does not appear but proceeds to the next screen.
The display of elapsed time since purchase or calibration test is the same.
Display
☞
'1.4 Maintenance Reminder Screen'
Use the following procedure to set the behavior
1 Switch to the function mode to display the [MAINTAIN]-[Maintenance Display].
☞
'3.1.2 Entering/Returning from the Function Mode'
2 Press the [CHANGE] switch.
3 Press the [ROTATION] switch to select the desired value.
Each time the switch is pressed, the value changes between on and off.
4 Press the [ENTER] switch to accept the displayed value.
To Next Page
