- 13 -
1.4 Maintenance Recommended Display
The SR-LEDW/SR-UL2/SR-UL1R/SR-3AR displays a maintenance reminder to run a calibration test
about once a year to maintain measurement accuracy. When the power is turned on, the screen
displays the number of months that have elapsed since the purchase or most recent calibration test
as shown in Figure A below. When one year has passed, the message shown in Figure B is
displayed. When this message is displayed, have your unit calibrated as soon as possible.
Figure A
* The number of months ranges from 0 to 11
Figure B
A buzzer rings for 5 seconds simultaneously with indication of Figure B, and the display advances to the
next screen automatically.
To automatically pass this process, set the setting for the maintenance recommended display to OFF.
Maintenance Recommended Display ☞ ‘3.19 Maintenance Recommended Display’
To Next Page
