- 11 -
1.3.4 Turning ON/OFF the Power
Flip the power switch to the right side to turn on the power.
When the power is turned on, the LCD screen will display an initialization screen, a maintenance
reminder screen and then the most recent measurement data.
Maintenance Recommended Display ☞ ‘1.4 Maintenance Recommend Display’
#10 AUTO ABS 2.0
x = 0.4476 2.0
y = 0.4074
Lv= 8.940E+01 cd/m^2
∙ The SR-3AR display “Start SR-3AR” in the initial display
** Start SR-UL1R**
Maintenance Recommend Display
Maintenance Last Time
n months passed.
*** Please Wait ***
System Check Running.
The display during checking the system
ON→
FUNCTION
SHIFT
LAMP
FIELD
DIF.
DC IN
POWER
Note
