- 32 -
3.1.3 Setting Values
In the function mode, it is necessary to input a numerical value for the item.
The procedure for inputting a numerical value is the same for all the items.
Setting of integral time will be explained here as an example.
1 Set to the function mode.
Select the [MEASURE] as one of function mode, and press [ENTER] switch.
And then the display appears as follows.
☞
'3.1.2 Entering/Returning from the Function Mode'
＊ Ｍｅａｓｕｒｅ Ｔｙｐｅ ＊
＊ＡＵＴＯ
2 Press the [CHANGE] switch. The cursor will be lit in the input stand-by status.
＊ Ｍｅａｓｕｒｅ Ｔｙｐｅ ＊
＊ＡＵＴＯ
3 Press the [ROTATION] switch to set the measurement mode to [MANU] mode. Each time
the [ENTER] switch is pressed, the measurement modes to be supported are displayed in
order.
☞
'3.3 Measurement Mode'
AUTO→FREQ→MANU→SYNC→FIX INTEG→FIX FREQ
4 Press the [ROTATION] switch once again, the display appears as follows.
＊ Ｉｎｔｅｇ Ｔｉｍｅ Ｉｎｐｕｔ ＊
Ｉｎｔｅｇ[ｍｓ] ＝ １０００
To Next Page
