Topcon SR-LEDW - USB Driver Installation

- 99 -
4.3 USB Driver Installation
The procedure for installing the USB Driver in the PC is as follows.
1 Place the CS-900A CD-ROM in the CD-ROM drive.
2 Select and double-click the “dpinst.exe” file in [¥USB_Driver¥{os name}¥ {x86} or {x64}]
folder in the CD-ROM via Explorer.
For example, in the case of Windows7(32bit), it becomes {USB_DRIVER¥Windows7¥x86}.
For example, in the case of Windows10(64bit), it becomes {USB_DRIVER¥Windows10¥x64}.
OS
Windows® 7 Ultimate(32bit／64bit)
Windows® 7 Professional (32bit／64bit)
Windows® 8.1 Pro (32bit／64bit)
Windows® 10 Pro (32bit／64bit)
3 The User Account Control Dialog appears. Click [OK] button.
4 The Device Driver Installation Wizard appears. Click [Next] button.
