4.1.13 KOR Command
Reads the current correction factor setting from the SR-LEDW/SR-UL2/SR-UL1R/SR-3AR.
KOR1:Reads out whether the current correction factor setting for spectrum is the enable/disable
state.
KOR2: Reads out whether the current correction factor setting for tristimulus value is the
enable/disable state.
1 : Enable 0: Disable
PC Command communication direction Measuring instrument
KOR+(Cr･Lf)
OK+(Cr･Lf)
Setting+(Cr･Lf)
OK+(Cr･Lf)
4.1.14 CIE Command
Sets the CIE Color Matching Function (visual field) setting in the SR-LEDW/SR-UL2/SR-UL1R/
SR-3AR.
CIE_#: The pound sign (#) is the CIE Color Matching function setting, either 2 or 10.
For the pound sign (#), use 0 for a 2° visual field and 1 for a 10° visual field.
PC Command communication direction Measuring instrument
CIE+(Cr･Lf)
OK+(Cr･Lf)
