- 121 -
Communication time
Temperature characteristic
Within ±3 % against luminance value
(The luminance of 20 °C should be standard in the range of 5 °C ~35 °C.)
Polarized light characteristic
Luminance 1 % or less Spectral radiance 2 % or less(400~780nm)
Calibration standard
TOPCON TECHNOHOUSE calibration standard (Standard light A / 23 °C ± 3 °C / 50 % ± 15 %RH)
Display
Dot matrix LC display (20 characters × 4 lines) with lighting
Interface
USB 2.0 (Full speed: 12 Mbps)
RS-232C
Communication speed: 4800/9600/19200/38400 BPS
Data length: 7 bit/8 bit
Parity: EVEN/ODD/NONE
Stop bit: 1 bit/2 bit
Power supply:
Provided AC adapter
Power consumption:
Approx. 34 W
Operation conditions:
Temperature: 5 °C~35 °C Humidity: 80 %RH or less
Storing conditions:
Temperature: -10 °C~50 °C Humidity: 80 %RH or less
External dimensions:
Approx. 150 mm (width) × 239 mm (height) × 406 mm (length)
Weight:
Approx. 5.5 kg (only main body)
