Topcon SR-LEDW - Page 26

- 15 -
3 When measurement is done, the results are displayed. The display details will differ according to
the measurement mode.
Measurement Mode
☞
‘3.3 Measurement Mode’
＃１０ ＡＵＴＯ ＡＢＳ ２．０ When AUTO is selected
ｘ ＝ ０．４４７６ １．０
ｙ ＝ ０．４０７４
Ｌｖ＝８．９４０Ｅ＋０１ ｃｄ／ｍ＾２
＃１０ ＦＲＥＱ ＡＢＳ ２．０ When FREQ is selected
ｘ ＝ ０．４４７６ １．０
ｙ ＝ ０．４０７４
Ｌｖ＝８．９４０Ｅ＋０１ ｃｄ／ｍ＾２
＃１０ ＭＡＮＵ ＡＢＳ ２．０ When MANU is selected
ｘ ＝ ０．４４７６ １．０
ｙ ＝ ０．４０７４
Ｌｖ＝８．９４０Ｅ＋０１ ｃｄ／ｍ＾２
＃１０ ＳＹＮＣ ＡＢＳ ２．０ When SYNC is selected
ｘ ＝ ０．４４７６ １．０
ｙ ＝ ０．４０７４
Ｌｖ＝８．９４０Ｅ＋０１ ｃｄ／ｍ＾２
＃１０ ＦＩＸ I ＡＢＳ ２．０ When FIX INTEG selected
ｘ ＝ ０．４４７６ １．０ （SR-LEDW only）
ｙ ＝ ０．４０７４
Ｌｖ＝８．９４０Ｅ＋０１ ｃｄ／ｍ＾２
＃１０ ＦＩＸ F ＡＢＳ ２．０ When FIX FREQ selected
ｘ ＝ ０．４４７６ １．０
ｙ ＝ ０．４０７４
Ｌｖ＝８．９４０Ｅ＋０１ ｃｄ／ｍ＾２
Each time a measurement is completed, the data number “#xx” will increase.
