108
BASIC OPERATIONS
DELETING MEASUREMENT V
A
LUES (RE
F/KRT MODE)
1
Press the
of the control
panel. P
AGE 2 is displ
ayed.
2
Press the
of the control panel
until the buzzer sounds" Pi!".
3
All measurement values, both
right and left eyes a
re cleared, and the system returns to
the initial status after power on.
P
AGE selecting button
P
AGE selecting button
CLEAR button
CLEAR button
108
110
