124
BASIC OPERATIONS
MEASUREMENT UNDER MANUAL MODE (TONO/PACHO MODE)
SETTING THE MANUAL MODE
In the initial status after power on, the mode is set to auto mode (AUTO).
1 Make sure the MEASUREMENT screen is on.
2 Press the of the control panel, set the measurement mode to
"MANUAL" and display the inner alignment mark on the monitor screen.
SETTING THE MEASUREMENT MODE
This instrument can select the measurement mode from T/P (ocular pressure/cornea thick-
ness continuous measurement), TONO (ocular pressure measurement) and PACHO (cornea
thickness measurement).
1 Make sure the MEASUREMENT screen is on.
2 Press the of the control panel and select the mea-
surement mode.
MEMO
Adjust the height of the automatic instrument table so that the patient
can sit on the chair comfortably and correct measurement values can be
obtained.
ALIGNMENT button
ALIGNMENT button
Inner alignment mark
MEASUREMENT MODE button
MEASUREMENT MODE button
To Next Page
