118
BASIC OPERATIONS
SETTING THE MEASUREMENT MODE
This instrument can select the measurement mode from T/P (ocular pressure/cornea thick-
ness continuous measurement), TONO (ocular pressure measurement) and PACHO (cornea
thickness measurement).
1 Make sure the MEASUREMENT screen is on.
2 Press the of the control panel and select the mea-
surement mode.
SETTING THE MEASURING RANGE
In this instrument, the measuring range can be switched in 2 steps between 0-30 and 0-60.
Normally, "0-30" is used, but if the patient's ocular pressure is high, switch it to 0-60. The initial
status after power on of the measuring range is 0-30.
1 Make sure the MEASUREMENT screen is on.
2 Press the .
MEASUREMENT MODE button
MEASUREMENT MODE button
PAGE selecting button
Page selecting button
To Next Page
